PARASOUND AMPLIFIERS
SPECIFICATIONS. Frequency response: 5 Hz - 55 kHz, +0/-1 dB, full output Total harmonic distortion: < 0.01% 1 kHz; < 0.03% 20 kHz IM distortion: < 0.03% Maximum output: > 8 V before clipping Input impedance: line input 30 kW; phono 47 kW Output impedance: 60 W Input sensitivity: line inputs 150 mV, +/- 5%; phono 2 mV Max input level: 10.5 V before clipping S/N ratio: line input > 92 dB, A-weighted, ref 1 V output line input > 84 dB, unweighted, ref 1 V output phono > 72 dB, ref .5 mV input Crosstalk: > 55 dB, 20 kHz Channel level matching: < 0.1 dB Voltage: Switchable for 110V - 120V or 220V – 240V operation Dimensions: 17-1/4" w x 4-1/8" h x 13-3/4" d, 3-5/8" h without feet
Net weight: 16 lbs.
SPECIFICATIONS. Continuous power output: 125 watts RMS x 2, 20 Hz - 20 kHz, 8W, both channels driven 200 watts RMS x 2, 20 Hz - 20 kHz, 4W, both channels driven 400 watts RMS x 1, 20 Hz - 20 kHz, 8W Current capacity: 45 amperes peak per channel Power bandwidth: 5 Hz - 100 kHz, +0/-3 dB at 1 watt Total harmonic distortion: < 0.06 % at full power IM distortion: < 0.04 % Slew rate: >130 V/µsecond Dynamic headroom: > 1.5 dB Interchannel crosstalk: > 80 dB at 1 kHz; > 63 dB at 20 kHz Input sensitivity: 1 V for 28.28 V, THX Reference Level Input impedance: 33 kW S/N ratio: > 112 dB, input shorted, IHF A-weighted Damping factor: > 800 at 20 Hz Voltage: Switchable for 110V – 120V or 220V – 240V operation Dimensions: 17-1/4" w x 4-1/8" h x 13-1/4" d, 3-5/8" h without feet
Net weight: 28 lbs.
SPECIFICATIONS. Continuous power output: 250 watts RMS x 2, 20 Hz - 20 kHz, 8 W, both channels driven 400 watts RMS x 2, 20 Hz - 20 kHz, 4 W, both channels driven 750 watts RMS x 1, 20 Hz - 20 kHz, 8 W Current capacity: 60 amperes peak per channel Power bandwidth: 5 Hz - 100 kHz, +0/-3 dB at 1 watt Total harmonic distortion: < 0.2 % at full power IM distortion: < 0.04 % Slew rate: >130 V/µsecond Dynamic headroom: > 1.5 dB Interchannel crosstalk: > 80 dB at 1 kHz; > 63 dB at 20 kHz Input sensitivity: 1 V for 28.28 V, THX Reference Level Input impedance: 33 k W unbalanced; 66 k W balanced S/N ratio: > 112 dB, input shorted, IHF A-weighted Damping factor: > 1100 at 20 Hz Voltage: 110V – 120V Dimensions: 17-1/4" w x 7-5/8" h x 19-1/8" d, 7" h without feet
Net weight: 60 lbs.
SPECIFICATIONS. Continuous power output, 20 Hz- 20 kHz: 400 watts RMS x 1, 8W 800 watts RMS x 1, 4W 1200 watts RMS x 1, 2W Class A power output, 20Hz – 20 kHz: 25 watts, bias set to high, 8W 10 watts, bias set to low, 8W Current capacity: 135 amperes peak Power bandwidth: 2 Hz - 120 kHz, +0/-3 dB at 1 watt Total harmonic distortion: < 0.15 % at full power IM distortion: < 0.03 % Slew rate: >130 V/µsecond Dynamic headroom: > 1.8 dB Input sensitivity: 1 V for 28.28 V output, THX Reference Level Input impedance: 100 k W S/N ratio: >120 dB, IHF A-weighted, bias set to high >122 dB, IHF A-weighted, bias set to low Damping factor: > 1200 at 20 Hz Power requirement: 250 watts, idle 1280 watts, full power into 4W DC trigger output capacity: +12 Vdc, 150 mA Dimensions: 17-1/4" w x 7-5/8" h x 20" d, 7" h without feet
Net weight: 64 lbs.
|
